Chem Lab in 151 INSCC.

Witec alphasnom: Confocal Raman, Photoluminescence.

FEI Nova NanoSEM 630: High resolution scanning electron microscope,(HRSEM SEM) EDS elemental analysis and mapping, e-beam lithography.






The high vacuum mode of the SEM has been fixed. For now, The SEM is still running in the old INSCC building.

And the Witec instrument (Raman/PL) is up and running in the new LSSB building, Floor B2, Room W0201.

3:50pm, 7/30/2025




High magnification image of tin balls on carbon. The ball at the bottom is 40nm and the one middle right is 8nm.
